TP-Link TL-SM311LM MiniGBIC Module
TP-Link TL-SM311LM MiniGBIC Module
Wave length: 850nm. Data rate: 1.25Gbps. Port type: LC/UPC. Cable length: 550m (1,800 feet) using 50/125um multi-mode fiber, 220m(720 feet) using 62.5/125um multi-mode fiber. Compatible with all SFP ports on TP-Link product including JetStream switches, and media converter MC220L. Work with MC200CM with multi-mode fiber connection. Limited lifetime warranty.
TP-Link TL-SM311LM MiniGBIC Module - For Data Networking, Optical Network - 1 x LC/UPC 1000Base-SX Network - Optical Fiber - 62.5/125 µm, 50/125 µm - 850 nm Wavelength - Multi-mode - 1.25 Gigabit Ethernet - 1000Base-SX - 1.25 Gbit/s - 0.22 km (0.14 Mile) Maximum Distance - 1 Each
Manufacturer: TP-LINK Technologies Co., Ltd
Manufacturer Part Number: 4888138
Manufacturer Website Address: http://www.tp-link.com
Brand Name: TP-Link
Product Model: TL-SM311LM
Product Name: TL-SM311LM MiniGBIC Module
Marketing Information:
Wave length: 850nm. Data rate: 1.25Gbps. Port type: LC/UPC. Cable length: 550m (1,800 feet) using 50/125um multi-mode fiber, 220m(720 feet) using 62.5/125um multi-mode fiber. Compatible with all SFP ports on TP-Link product including JetStream switches, and media converter MC220L. Work with MC200CM with multi-mode fiber connection. Limited lifetime warranty.
Packaged Quantity: 1 Each
Product Type: SFP (mini-GBIC)
Application/Usage:
- Data Networking
- Optical Network
Total Number of Ports: 1
Connector Type: LC/UPC
Interfaces/Ports Details: 1 x LC/UPC 1000Base-SX Network
Media Type Supported: Optical Fiber
Fiber Optic Cable Core/Cladding Specification:
- 62.5/125 µm
- 50/125 µm
Fiber Mode Supported: Multi-mode
Ethernet Technology: 1.25 Gigabit Ethernet
Network Technology: 1000Base-SX
Maximum Distance Supported: 0.22 km (0.14 Mile)
Maximum Data Transfer Rate: 1.25 Gbit/s
Minimum Operating Temperature: 32°F (0°C)
Maximum Operating Temperature: 158°F (70°C)
Height: 0.20" (5.08 mm)
Width: 0.20" (5.08 mm)
Length: 0.20" (5.08 mm)
Weight (Approximate): 0.16 oz (4.54 g)
Package Contents:
- TL-SM311LM MiniGBIC Module
- Installation Guide
- TP-Link MC220L Gigabit Ethernet Media Converter
TP-Link Switches:
- T3700 series
- T2700 series
- T2600 series
- T2500 series
- T1700 series
- T1600 series
- T1500 series
- 2/3/5 series
Environmental Compliance:
- Restriction of Hazardous Substances (RoHS)
- Waste Electrical and Electronic Equipment Directive (WEEE)
Limited Warranty: Lifetime
Product Numbers: 845973030209
